Description
- Triple Fan:Â Three fans and a huge heatsink ensure a cool and quiet experience for you.
- TORX FAN 4.0:Â A masterpiece of teamwork, fan blades work in pairs to create unprecedented levels of focused air pressure.
- Copper Baseplate:Â A solid nickel-plated copper baseplate transfers heat from the GPU to all heat pipes for better cooling.
- Core Pipe:Â Precision-machined heat pipes ensure maximum contact with the GPU and spread heat along the full length of the heatsink.
- Airflow Control:Â Airflow Control guides the air to exactly where it needs to be for maximum cooling.
- Reinforcing Backplate:Â The reinforcing backplate features a flow-through design that provides additional ventilation.
- MSI Center:Â The exclusive MSI Center software lets you monitor, tweak, and optimize MSI products in real-time.
- Afterburner:Â Take full control with the most recognized and widely used graphics card overclocking software in the world.
| Colour | |
| Primary Colour | Black |
| Dimensions | |
| Length | 308 mm |
| Width | 120 mm |
| Height | 43 mm |
| Water Cooling | |
| Watercooling | No |
| Clock Speeds | |
| Max. Memory Clock | 18000 MHz |
| Max. GPU Clock (Boost) | 2580 MHz |
| Max. GPU Clock (Base) | 2310 MHz |
| Lighting | |
| Lighting | No |
| Standards / Specifications | |
| Adaptive Sync Technology (G-Sync / Freesync) | NVIDIA G-Sync |
| Graphics Card | |
| GPU Series | RTX 40 Series |
| Expansion Slots | |
| Expansion Slots Required | 2 Slots |
| Cooling | |
| Number of GPU Fans | 3 |
| External Ports | |
| Display Connectors | HDMI (1x), Display Port (3x) |
| Internal Ports | |
| Required Power Connectors | 8-pin PCIe (1x) |
| GPU Model | |
| GPU Series Name | NVIDIA GeForce RTX 4060 Ti 8GB |
| Graphics Chip | AD106-350 |
| Manufacturing Process | 4 nm |
| Shader Units | 4352 |
| Tensor Cores | 136 |
| Raytracing Cores / Ray Acceleratorss | 34 |
| GPU Memory Type | GDDR6 |
| Slot Type Standard | PCIe 4.0 |
| GPU Memory Size (GB) | 8 |
| GPU Memory Interface (bit) | 128 |
| GPU Memory Bandwidth (GB/s) | 288 |
| GPU Effective Memory Clock (MHz) | 18000 |
