Description
System Power 10 850W has been built with price-conscious users in mind that do not want to dispense on reliability and quietness. Features such as LLC + SR + DC-to-DC topology and Dual-Rail operation underline the value System Power 10 850W offers even at entry-level.
System Power 10 at a Glance
- 80 PLUS® Gold efficiency (up to 93.4%)
- Advanced stability and voltage regulation thanks to LLC, SR and DC-to-DC
- Silence-optimized 120mm be quiet! fan reduces system noise
- Rock-solid stability with 2 strong 12V-rails
- Dependable operation to support powerful GPUs
- Stand-by drain of less than 0.15 watts
System Power 10 Specification
| Model | System Power 10 850W |
|---|---|
| Continuous power (W) | 850 |
| Peak power (W) | – |
| Form factor | Version 2.52 |
| Form factor EPS 12V | Version 2.92 |
| Topology | LLC + SR + DC/DC |
| Digitally controlled | – |
| Voltage (Vac) | 200 – 240 |
| Frequency (Hz) | 50 |
| Input current (A) | 5 |
| Power factor at 100% load | >0.97 |
| Modern standby | – |
| Power consumption in standby (W) | <0.15 |
| Average life time (h / 25°C) | > 100,000 |
| Operating temperature up to (°C) | 40 |
| Dimensions | |
| Length / Depth | 140 mm |
| Width | 150 mm |
| Height | 86 mm |
| Lighting | |
| Lighting / RGB | No |
| Power Specifications | |
| Total Power Output | 850 W |
| Efficiency Class | |
| 80PLUS Efficiency | 80 PLUS Gold |
| Fan Specifications | |
| Fan Size | 120 mm |
| Colour | |
| Primary Colour | Black |
| Power Supply | |
| PSU Format | ATX |
| 12V Distribution | multi rail |
| Modular Power Supply | No |
| Cooling | |
| Semi Passive Power Supply | Yes |
| Internal Ports | |
| CPU Power Connectors 12V ATX/EPS | 1 |
| 12VHPWR PCIe Power Connectors | 0 |
| 8 Pin PCIe Power Connectors | 1 |
| 6+2 Pin PCIe Power Connectors | 4 |
| SATA Power Connectors | 6 |
| Cable Specifications | |
| Max. CPU Power Cable Length | 810 mm |
| Max. 24-Pin Motherboard Power Cable Length | 600 mm |
