Description

High efficiency with 80 PLUS Gold certification
24/7 continuous power output with 50c operating temperature
100% modular design with universal EPS / PCIe connector interface for maximum flexibility
Ultra silent 135mm FDB fan with semi-fanless and delayed shut-off function
Strict ±2% voltage regulation and low ripple & noise
All Japanese capacitors

Flat cables have much greater flexibility to allow for tighter folding and management of cables
180mm depth sets new standard for 1650W+ PSUs with modular cables
Powerful single +12V rail design, perfect for high-end components, upgrades and overclocking
±2% regulation and low ripple & noise performance for high stability
Ultra silent 135mm FDB fan with intelligent RPM control provides cool performance at higher loading conditions and silent operation during idle to low loading conditions. Fanless mode operation works up to 30% loading (495W)

Max. DC Output: 1650W
Power density: 711W per liter
Color: Black.(Lead-Free Paint)
Combined +3.3V & +5V: 130W
Combined +12V: 1650W
Input Voltage: 90V~264V
Input Frequency Range: 47Hz ~ 63Hz
PFC: Active (PF>0.9 at Full Load)
Efficiency: 87% ~ 90% (at 20% ~ 100% loading)
MTBF: 100,000 hours
Operating temperature: 0°C ~ 50°C

Protection
Over current protection
Over power protection
Over voltage protection
Short circuit protection
Under voltage protection
Over temperature protection

Connectors
1 x 24 / 20-Pin motherboard connector (600mm)
4 x 8 / 4-Pin EPS / ATX 12V connector (“750mm” x 4)
8 x 8 / 6-Pin PCIe connector (“600mm / 150mm” x 4)
4 x 8 / 6-Pin PCIe connector (“600mm” x 4)
16 x SATA connector (“600mm / 150mm / 150mm / 150mm” x 4)
6 x 4-Pin Peripheral connector (“600mm / 150mm / 150mm” x 2)
1 x 4-Pin Floppy adapter connector (100mm)

Cooling System: Single 135mm FDB fan
Form factor: ATX / PS/2
Noise Level: 0dBA ~ 36dBA
Dimension: 150 mm (W) x 86 mm (H) x 180 mm (D); 5.91″ (W) x 3.39″ (H) x 7.09″ (D)
Weight: 2.09 kg
Certification: 80 PLUS Gold
